How to Strategically Plan EMC-compliant PCB Stack-Ups

Kenneth Wyatt

Principal Consultant
Wyatt Technical Services LLC

Vandana CC

Engineering Project Coordinator
Sierra Circuits

Download Slides

Suppose you have followed every recommended layout guideline to ensure EMC, yet your design fails during signal integrity simulation. Where did things go wrong? The root cause lies in a decision made long before the first trace was routed, the stack-up.

In this webinar, you’ll learn how to engineer EMC-compliant PCB stack-ups that reduce design iterations and ensure signal integrity.

Practical strategies for designing high-performance stack-ups

Before creating the stack-up, you must define your design requirements. Identify your product’s electrical, mechanical, and thermal constraints early in the design cycle.

Determine operating frequency, target impedance, and current-carrying requirements. Categorize RF, analog, power, and sensitive signals so that each can be assigned a suitable routing layer and reference plane.

Next, select laminate materials based on electrical performance. Evaluate dielectric constant, dissipation factor, glass transition temperature, CTE, moisture absorption, and dimensional stability according to your application’s operating frequency and environmental conditions.

For a perfect stack-up strategy, you must choose the appropriate transmission line structure. Use stripline routing whenever lower radiation and better EMI immunity are required because the traces remain enclosed between reference planes. Adopt coplanar waveguides for RF applications, requiring improved field confinement.

To build an EMC-optimized layer stack, position high-speed signal layers adjacent to solid reference planes. Keep power and ground planes closely coupled to increase interplane capacitance. You should also maintain a symmetrical stack-up to improve both EMC performance and manufacturing reliability.

Finally, prepare complete and accurate stack-up documentation. Specify dielectric thicknesses, copper weights, finished board thickness, layer sequence, and impedance requirements. Review the proposed stack-up with your fabricator during the design phase so that your board is manufacturable.

By the end of this session, you’ll understand how to transform a stack-up from planning to a perfectly well-built board. Join this webinar and gain practical approaches for creating EMC-compliant PCB stack-ups.

What you’ll learn:

• How EMC problems originate due to poor stack-up planning
• Defining design requirements before planning a stack-up
• Selecting the best laminate for your prototypes
• Choosing the right transmission line
• Building an EMC-optimized layer stack
• Solid ground planes vs. copper pours
• Tips to avoid board warping and mechanical stress
• Stack-up information your fabricator needs
• Q&A by Kenneth Wyatt
