Healthcare & Medical PCBs

ISO 13485:2016 certified — Sierra Circuits fabricates and assembles cutting edge PCBs that meet stringent medical-grade criteria.

Start a Custom Quote

The Healthcare & Medical PCB applications we serve

Sierra Circuits fabricates and assembles medical PCBs for a wide range of medical devices, such as:

  • Medical imaging devices
  • Medical monitoring systems
  • Robotic surgery
  • Radiation therapy or radiotherapy

The testing standards we follow for Medical PCBs

We perform constant testing at each step of the manufacturing process to ensure reliability of the medtech circuit boards.

  • Automated optical inspection (AOI): AOI captures images of the PCB with either a single 2D camera or two 3D cameras. The captured image is compared with the schematic. If the board does not match the schematic, the board is sent to manual inspection.
  • Solderability test: Ensures that the solder joints are reliable.
  • Ionic contamination testing: Ionic contamination testing is performed to detect ionic residues resulting from the fabrication and soldering steps.
  • Peel test: Determines the measure of strength required to peel the laminate from the circuit board.
  • Micro-sectioning analysis: The inspection is carried out to determine the quality of the circuit board and also to spot internal failures.
  • Flying probe test: Test probes move from test points to other test points and check for opens, shorts, other issues.
  • Time-domain reflectometer (TDR): TDR impedance measurements are essential for ensuring signal integrity. It also checks for electrical discontinuities in connectors, or any other electrical path.
» MORE

Sierra Circuits manufactures durable, reliable, thermal resistant Medical PCBs.
Start an online quote for PCBs that meet your medical-grade requirements.

How we meet your high-reliability requirements with full traceability

Under IPC-6012 class 2 and class 3, we build standard, advanced, and micro boards with high accuracy. Our advanced boards come with UL 94 V-0 flammability standards. We provide the following documentation and certificates:

  • Certificate of conformance
  • Material specifications
  • First article inspection report
  • Reflow profile copy (included with the first article)
  • Photo requirements
  • IPC J-STD-001E
  • Record of all the calibrated tools used during manufacturing
  • AOI report or visual inspection report
  • Flying probe or in-circuit testing report
  • Ionic cleanliness test report

We follow the below standards that help us build high-quality, reliable Medical PCBs for the Healthcare & Med-Tech industry.

  • IPC 6011: Defines performance specification for class 1, class 2 and class 3 PCBs
  • IEC 60601-1: General requirements for basic safety and essential performance of medical electrical equipment
  • IEC 60601-1-2: Defines electromagnetic requirements (EMI and EMS) of medical PCBs
  • ISO 13485: Provides quality management system requirements for medical equipment

We offer DFM/DFA checks on every board

We specialize in DFM and DFA analysis that prevent issues and offer internal quality review systems that guarantee zero-defect boards. We also provide engineering support to verify if your design is set to perform as expected and IPC class 3 compliant, should you go for this standard.

» MORE

Need a Medical PCB assembly partner with transparent pricing?
We offer several options for ordering parts and assembly.

Extensive electrical testing for Medical PCBs

We do not bargain on quality and follow the stringent fabrication criteria that medical boards require – this means constant testing at each step of the manufacturing process, such as cross-section, AOI, BGA X-ray, flying probe, and other electrical tests.

Fab and assembly under one roof

The miscommunications between separate fabrication and assembly shops will cause delays in deliveries and errors in your board. A PCB manufacturer that does not handle assembly won’t run DFA checks to ensure your board can properly be assembled. One single vendor is accountable.

How to get a quote for Medical PCBs

Let us run DFM/DFA analysis for you and get back to you with a report. You can upload your files securely through our website.

We require the following information in order to give you a quote:

  • Gerber, ODB++ or IPC-2581
  • BOM if you require assembly
  • Quantity
  • Turn time
Advanced PCBs PCBs manufactured and assembled in the United States

The Highest Quality IPC Class 3 Boards

Made in America. Shipped from Silicon Valley.

Start a Secure Quote

Fully Assembled PCBs, Made in the USA. For all healthcare and medical applications

Illustration: DFM and DFA Checks

DFM & DFA Checks on every board

Live engineering support and software accelerated checks on all orders.

Illustration: Extensive Electrical Testing

Extensive Electrical Testing

Cross-section, AOI, BGA X-ray, and flying probe to name a few.

Illustration: Fab and Assembly Under One Roof

Fab + Assembly under one roof

Avoid delays by using a single vendor for fab, assembly, and testing

Sierra Circuits engineers can deliver -/+ 5% impedance tolerance for your complex & HDI PCBs.

Sierra Circuits in-house engineers will...

  • Help you with your stack-up.
  • Route your single-ended and differential pair traces.
  • Place your components, vias, coupling capacitors.
  • Adjust the length matching to achieve propagation delay.
  • Calculate the effective dielectric constant.
Contact a Sierra Circuits Specialist

Talk to a Sierra Circuits PCB Expert today

24 hours a day, 7 days a week.

Call us: +1 (800) 763-7503
Email us: through our Customer Care form
