Webinar: Ultra-HDI PCB Design and Manufacturing
REGISTER NOW
September 16th, 2026 | 9 AM PT
COST: FREE
-
24
Days
-
21
Hours
-
46
Minutes
-
22
Seconds
Amit Bahl
CRO at Sierra Circuits
This webinar will be hosted on Zoom.
Following this event, you will receive:
-
Slides
-
Recording
Webinar abstract:
Ultra-high density interconnect PCBs enable extremely high routing density through thin dielectric layers (<1.2 mil) and fine conductor geometries (<2 mil). When features shrink to this scale, every manufacturing variable matters. Material movement, stack-up design, laser drilling, and plating collectively determine whether an ultra-HDI design can be successfully manufactured.
In this webinar, you’ll get a closer look at UHDI PCB design and manufacturing challenges. You’ll also learn about the design techniques that can turn ultra-fine designs into successful prototypes.
Building reliable Ultra-HDI printed boards
Generally, PCB materials like FR4, Tachyon 100G, and Panasonic Megtron 6 comply with mSAP board fabrication. Opt for high-Tg laminates to support laser drilling and withstand multiple lamination cycles.
At sub-2-mil geometries, variations in copper thickness and surface profile can directly affect trace definition and imaging accuracy. Ask your fabricator to use very-low-profile (VLP) copper to achieve accurate trace dimensions. VLP copper can help achieve more consistent conductor geometries and improve fine-line fabrication.
As the number of lamination cycles increases, dimensional movement might create layer-to-layer misalignment. To avoid this, use hybrid build-ups. Have additive layers for high-density signal routing and subtractive layers for power, ground, and lower-density signals. Maintain a symmetrical build-up and balanced copper distribution to minimize warpage.
REGISTER NOW
When designing with ultra-fine circuits, understanding the potential manufacturing constraints is essential. The predominant issue is that the glass structure might influence dimensional stability. The interaction between the glass weave, dielectric thickness, and copper pattern density can affect fine-line alignment.
Plating introduces another set of challenges. At very small via geometries, achieving uniform copper deposition becomes more difficult, particularly when current density varies across the panel. Small microvias and challenging aspect ratios can increase the risk of incomplete copper coverage.
Imaging and registration become equally critical as line widths and spaces approach ultra-fine dimensions. Minor layer shifts, photoresist variations, or process distortions can translate into significant dimensional errors at the finished board level.
In this session, our manufacturing experts will walk you through these fabrication challenges and explain the process controls used to address them.
By the end of the webinar, you’ll learn how material selection, stack-up design, laser drilling, and plating come together to support reliable UHDI PCB design and manufacturing.
Register now and see how ultra-fine PCB designs turn into a manufacturable reality.
Webinar agenda:
-
What is ultra-HDI?
-
UHDI vs conventional HDI
-
Material selection for UHDI compatibility
-
Resin flow around dense copper features
-
How glass structures influence laser drilling
-
Stack-up considerations for minimizing registration errors
-
Plating and imaging challenges at 2-mil-and-below geometries
-
mSAP process for a successful ultra-HDI
-
DFM guidelines for UHDI fabrication
-
Questions for your PCB manufacturer before starting a UHDI design
