RF Series 2/4: Techniques for Building Reliable RF PCB Stack-Ups

REGISTER NOW
Banner image

August 21st, 2025 | 10 AM PT

COST: FREE

  • 13

    Days

  • 23

    Hours

  • 39

    Minutes

  • 33

    Seconds

Amit Bahl

CRO at Sierra Circuits

This webinar will be hosted on Zoom.

Following this event, you will receive:

  • button icon Slides

  • button icon Recording

Webinar abstract:

In high-frequency PCB designs, the stack-up is not just a structural element; it’s the foundation of your RF board’s performance. A poorly built-up stack-up might result in insertion loss, impedance discontinuities, skew, and electromagnetic interference. Whether you’re developing a basic prototype or an mmWave board, designing stack-ups with precision is critical to achieve signal fidelity.

In this webinar, you’ll learn practical techniques for designing RF PCB stack-ups that deliver consistent performance across various frequency ranges.

Practical strategies for designing high-performance radio-frequency stack-ups

Before choosing a stack-up, it’s essential to define your target operating frequency range, controlled impedance requirements, trace geometries, and grounding strategy.

Once the requirements are mapped out, the next step in designing RF PCB stack-ups is selecting the appropriate laminate. Choose materials with a stable and low dielectric constant (Dk) and a low dissipation factor (Df) to minimize insertion loss and phase distortion. Recommended RF materials include Rogers RO4350B (Dk=3.48, Df=0.0037 at 10 GHz), Isola Astra MT77 (Dk=3.0, Df=0.0017), or Panasonic Megtron 6 (Dk=3.35, Df=0.004 at 10 GHz).

REGISTER NOW

After material selection, you should shift to the reference plane configuration. Ensure signal layers are tightly coupled to reference planes to minimize loop inductance and suppress common-mode radiation. To enhance shielding and field containment, add fencing or stitching vias. Ensure the via-to-via spacing doesn’t exceed λ/20, where λ is the operating wavelength.

An important consideration in designing radio-frequency stack-ups is selecting the appropriate transmission line structure. For many RF applications, grounded coplanar waveguides (GCPW) offer excellent field confinement and isolation. Microstrip and stripline configurations may also be suitable, depending on your stack-up and routing constraints.

To ensure your design is both functional and manufacturable, account for fabrication tolerances such as layer registration accuracy and dielectric thickness variations. Close collaboration with your manufacturer during the stack-up planning phase ensures material availability, impedance accuracy, and stack-up feasibility. As a best practice, document your stack-up in detail; include impedance targets, material specs, and layer assignments.

If you’re working on RF prototypes and want to ensure they’re ready for manufacturing, this webinar is for you.

In this session, we’ll guide you through real-world strategies for designing RF PCB stack-ups. Reserve your spot now and take the first step toward creating better RF boards.

Webinar agenda:

  • button icon Stack-up design can make or break your RF board
  • button icon How to select the best laminate for your prototypes
  • button icon How to arrange reference planes to prevent coupling
  • button icon RF stack-up configurations for transmission lines:
    • o Coplanar waveguide
    • o Microstrip
    • o Stripline
  • button icon Tips to avoid board warping and mechanical stress
  • button icon Things you must include in your stack-up details
